Fully Automatic Rubber Cutting Machine is an industrial hydraulic cutting system designed for high-efficiency processing of rubber materials such as natural rubber, silicone, nitrile rubber, EPDM, fluororubber, and recycled rubber.
Manufactured by Xinzhe Blades, a professional manufacturer, supplier, and factory in China, the machine is engineered to solve key industry problems such as material sticking, deformation, uneven cutting, and low manual efficiency.
It is widely used in rubber manufacturing plants, sealing product factories, silicone processing workshops, and recycling industries.
The Fully Automatic Rubber Cutting Machine is used for:
· Fixed-length cutting of rubber blocks and strips
· Batch sizing for production lines
· Pre-processing before mixing or molding
· High-precision rubber material preparation
It replaces manual cutting and improves consistency in industrial production.
· High-hardness alloy steel blade
· Vacuum heat-treated and precision ground
· Anti-stick surface treatment
· No sticking, no tearing, smooth cutting
· Strong and stable cutting force
· Suitable for thick and hard rubber blocks
· One-time clean cut without deformation
· CNC touchscreen operation
· Cutting length adjustable
· Accuracy up to ±0.1mm
· Stable batch consistency
· One-button start/stop
· Parameter memory function
· Low operator requirement
· Suitable for continuous production Industrial Durability· Heavy-duty welded steel frame
· Stable 24-hour operation
· Low vibration and low maintenance
|
Item |
Specification |
|
Machine Name |
Xinzhe Blades Fully Automatic Hydraulic Rubber Cutting Machine (Vertical Type) |
|
Core Configuration |
Xinzhe Original Anti-Stick Wear-Resistant Alloy Cutting Blade |
|
Applicable Materials |
Natural rubber, synthetic rubber, nitrile rubber, silicone rubber, fluororubber, recycled rubber, rubber rolls, rubber blocks, rubber strips |
|
Cutting Thickness Range |
0.5 mm -200 mm (customized heavy-duty models available) |
|
Cutting Length Range |
10 mm -9999 mm (fully adjustable fixed length cutting) |
|
Cutting Accuracy |
±0.1 mm high precision |
|
Drive System |
Industrial hydraulic drive with stable adjustable pressure |
|
Hydraulic Pressure Options |
10T / 20T / 30T optional configurations |
|
Rated Power |
2.2 kW / 3 kW / 4 kW industrial-grade copper motor |
|
Rated Voltage |
220V / 380V (customized export voltage available) |
|
Operation System |
CNC touchscreen control, parameter memory, one-key start/stop, dual mode foot pedal control |
|
Key Features |
Anti-stick cutting, no material pulling, burr-free cutting surface, stable long-term precision |
The Fully Automatic Rubber Cutting Machine is widely used in:
· Rubber product manufacturing
· Silicone sealing parts production
· Tire recycling and rubber regeneration
· Industrial gasket and pad production
· Rubber compounding workshops
It is suitable for both soft and hard rubber materials.
Produced by Xinzhe Blades factory in China, the machine follows strict quality control:
· ISO9001 quality system
· CE export certification
· Full machine load testing before shipment
· Blade hardness and anti-stick performance testing
Each Fully Automatic Rubber Cutting Machine is tested under real rubber materials before delivery.
|
Comparison Item |
Standard Rubber Cutting Machine |
Xinzhe Blades Rubber Cutting Machine |
|
Core Blade Configuration |
Ordinary white steel blade or low-grade alloy blade, no anti-stick treatment, easy sticking, chipping, and frequent blade damage |
Xinzhe self-developed anti-stick alloy blade with precision polishing, wear-resistant, non-stick, and 3× longer service life |
|
Cutting Material Performance |
High-elastic rubber easily stretches, tears, deforms, with rough and uneven cutting surfaces |
Smooth and clean cutting surface, no burrs, no deformation, consistent results for both soft and hard rubber |
|
Thick Material Cutting Ability |
Insufficient power, unable to cut through thick rubber, easy jamming and misalignment |
Hydraulic high-power system ensures one-time clean cutting of thick and dense rubber without residue |
|
Fixed-Length Precision |
Manual adjustment leads to large deviation, inconsistent batch size, high material waste |
CNC precise control with ±0.1mm accuracy, consistent batch output, maximum material utilization |
|
Operating Cost |
Frequent blade replacement, secondary trimming required, high hidden production cost |
Long-life blade, no frequent replacement, no rework required, significantly lower operational cost |
|
Operational Stability |
Vibration, pressure loss, and misalignment during long operation, unsuitable for continuous production |
Reinforced frame with stable hydraulic system, supports 24-hour continuous operation without failure |
|
After-Sales & Spare Parts |
No dedicated blade system, difficult spare parts sourcing, slow service response |
Factory-direct supply of machine and anti-stick blades, fast spare parts availability, 24-hour technical support |
We provide flexible customization for different industrial needs, including:
· Heavy-duty thick rubber cutting machine customization
· Extra-wide rubber roll cutting system customization
· Special anti-stick blade customization for different rubber materials
· Export voltage customization (220V / 380V / other standards)
· Automatic feeding and discharge system customization
· High-precision fine adjustment system customization
Each solution is designed based on customer material type, thickness, cutting size, and production capacity requirements to ensure optimal performance.
Our production follows a strict industrial standard workflow:
With dual quality control of anti-stick blade technology and hydraulic system precision engineering, Xinzhe Blades ensures stable cutting performance, long service life, and consistent accuracy while effectively eliminating issues such as sticking, deformation, blade chipping, and dimensional deviation.
Xinzhe Blades is a professional manufacturer, supplier, and factory in China specializing in rubber cutting systems and industrial blade solutions.
With strong R&D and manufacturing capability, we focus on:
· High-precision cutting technology
· Wear-resistant blade engineering
· Stable industrial automation systems
The Fully Automatic Rubber Cutting Machine is one of our core solutions for global rubber processing industries.
Can it cut soft silicone and sticky rubber?
Yes. The anti-stick blade prevents sticking and deformation.
Can it cut thick rubber blocks?
Yes. Hydraulic power ensures clean cutting even for dense materials.
Is the cutting size stable?
Yes. CNC system ensures ±0.1mm accuracy.
Is it suitable for 24-hour production?
Yes. It is designed for continuous industrial operation.
Is it easy to operate?
Yes. Touchscreen control allows fast setup with minimal training.
